6-3
6. Maint.
Instructions for Use Manual 6 Maintenance
3. Push up on the battery latch. Remove the drained
battery.
Figure 6.4 Removing the Battery
4. Replace with a fully charged battery.
NOTE: The battery is keyed to allow only insertion from bottom
rst then push in top.
Figure 6.5 Replacing with a Fully Charged Battery
5. Replace the battery cover.
6. Place the drained battery into the Charging Station.
This
Contacts to
This
StatStrip Glu IFU 1.86 PN55848E EN 510K.indd 3 9/13/18 8:29 AM
