Nytech DS-8210 Introduction
English - 7
Controls and buttons
This User manual has a fold-out cover. On the inside of the cover the
camera is shown with the meanings of the controls and buttons.
Figure of back
1 On/Off button (Power)
2 Power indicator
3 Shutter
4 Zoom button
5 Playback button (Play)
6 Menu button
Figure: Four-way button
7 Eyelet for carrying strap
8 SET button
9 Four-way button
for Menu navigation (see right)
10 Camera mode button
11 Delete/ASM
12 Display
Figure of front
13 Self-timer lamp and auto focus lamp
14 Flash
15 Lens
16 Microphone
Bottom
17 Speaker
18 Tripod mount
19 Battery cover and
memory card compartment
17 18 19
