3-22 Print Controller User’s Guide
Chapter 3 Printer Driver Functions
Features - Punch
[Left], [Top] makes each punched set of copies and outputs to the tray of the finisher.
Punching is performed as shown for the following orientations:
Left (Portrait) Left (Landscape)
Top (Portrait) Top (Landscape)
[Punch] can not be performed in the following cases:
• When Finisher is not available
• When [5.5” x 8.5”], [8.5” x 14”], [A5], [A6], [F4], or wide paper is selected in [Paper
size]
• When [OHP (Transparency)], [OHP-Interleave (Blank)], [OHP-Interleave (Print)], [Tab
sheet] is selected in [Media Type]
• When [Collate] is not selected in [Copies]
• When any of [Fold], [Stitch] or [Trim] is set in [Features]-[Fold&Stitch]
• When [Sub Tray] is selected in [Output Tray]
• The following combination is selected
e.g., [Staple - Top] and [Left]
Refer to the diagram on the next page for the paper size, punching and
punching & stapling combination.
