26 Océ TDS320 User Manual
Cut media
If the material does not have a straight leading strip, you can cut the material
at right angles from the roll.
▼ Cut the material from roll 1 or roll 2
1 Open the drawer.
2 Feed the paper manually until it is 5 cm above the top drawer.
3 Press the On-line key to put the printer off-line.
4 Close the paper drawer.
5 Select the ‘Media settings’ item with the or key.
6 Press Next/select to enter the ‘Media settings’ menu.
7 Select ‘Cut media’ with the or key.
8 Press Next/select to cut the paper.
9 Open the paper drawer.
10 Remove the scrap of material.
11 Feed the material until you can see the material and put the material into
position
(see figure 46 on page 113) and (see figure 50 on page 115).
12 Close the drawer.
13 Press the On-line key to put the printer on-line again.
