OHAUS Explorer Balances - Opening the Base Module (Top Loader)

CHAPTER 3 - MAINTENANCE / REPAIR PROCEDURES
Ohaus Corporation www.ohaus.com 26 Explorer
®
Series Service Manual
9. Disconnect the Bubble Light Cable from the Connect PCBA. The Top Housing can now be
separated.
3.2.4 Opening the Base Module (Top Loader)
1. Prepare the balance as instructed above.
2. Turn the base on its side and remove the 4 screws that hold the Top Housing to the Base. Do
not turn the Base completely over as the weight of the Base will rest on the Load-cell possibly
causing damage.
