OHAUS Explorer Balances - Opening the Base Module with a Draftshield

CHAPTER 3 - MAINTENANCE / REPAIR PROCEDURES
Ohaus Corporation www.ohaus.com 24 Explorer
®
Series Service Manual
3.2.3 Opening the Base Module with a Draftshield
1. Prepare the balance as instructed above.
2. Remove the EMC Screw and Plate from the Base
3. Remove the Back Plate
4. Disconnect the Light Cable.
Screws that secure the Back Plate
