CHAPTER 5 - PARTS LISTS & DIAGRAMS
Ohaus Corporation www.ohaus.com 58 Explorer
®
Series Service Manual
TABLE 5-3 BASE SPARE PARTS (DRAFTSHIELD MODELS)
Item
Description
1
Pan, 90mm
1
Pan, 130mm
2
Pan Support, 130mm
3
Wind-ring, 90mm
4
EMC Plate - DS
5
Top Housing, DS
6
IR Sensor PCBA
7
Base
8
Latch, Front Panel
9
Level Bubble
10
Main PCBA
11
Connect PCBA
12
Load-cell Cover
13
Load-cell
16
Foot Kit
18
Cable Kit (not all shown)
20
Hardware Kit (not all shown)
Not shown
Box, DS
Not shown
Packaging Complete, DS
