Oki Data CONFIDENTIAL
42930511TH Rev. 2
128 /
3
1
Latch
4
2
4.3.21
Paper Feed Roller
(1)
Open the tray 1 side cover
1
and the paper guide
2
.
(2)
Pull out Tray
3
.
(3)
Pull outward the latches of the 3 paper feed rollers
4
, and remove from the shaft.
127
