Oki C9600 - 7.5.3 Troubleshooting With Abnormal Image

Oki Data CONFIDENTIAL
42930511TH Rev. 2 200 /
A On the overall too
light or uneven print
D
Black Band/ Black
Stripe in Vertical
Direction
B
White Area Gets
Dirty
E
Abnormal Periodicity
C
Blank
F
White Band/White
Strip in Vertical
Direction
G
Stripe in Horizontal
Abnormal Image
The overall image is too light or uneven, or the color tone is off
centered, on the overall, while printing the image. (Figure 7-2 A )
The white area gets dirty. (Figure 7-2 B )
Blank sheet is output. (Figure 7-2 C )
A band or stripe print appears in the vertical direction of the printout.
(Black Band, Color Band, Black Stripe, Color Stripe). (Figure 7-2 D )
A white band, white stripe, uneven color band or uneven color stripe
occurs in the vertical direction.(Figure 7-2 F )
Defective Fusion (the image smears or peels off when touched).
Periodicity Abnormality (Figure 7-2 E )
Printout Falloff
Color Offset
Stripe in Horizontal Print Direction (Figure 7-2 G )
Flow Chart No
1
2
3
4
5
6
7
8
9
0
7.5.3 Troubleshooting With Abnormal Image
Troubleshooting with printout results that are irregular as shown in the diagrams below, are indicated.
Figure 7-2
