Oki Data CONFIDENTIAL
42930511TH Rev. 2 138 /
No5-1 Stacker Full FD SNS
No5-1 Stacker Full FD SNS
No32-1
Dup IN1 SNS
15-1 MPT PE SNS
15-2 MPT PE SNS2
16-1 MPT Hopping SNS
8-1 Hum SNS, 8-2 Temp SNS
8-1 Hum SNS, 8-2 Temp SNS
6-4 Media Weight SNS
1-3 WR SNS
1-2 IN2 SNS
16-2 MPT Home SNS
1-1 IN1 SNS
18-1 1stHopping SNS
32-3 Dup F SNS
Density SNS
6-1,2 Alignment L,R SNS
33-1 Dup IN2 SNS
No19-1~No19-4
1stPaper Size SW
No5-4 JobOffset HP SNS
No22-1~No22-4
1stPaper Size SW
21-1 2ndHopping SNS
20-2 2ndPaper Near END SNS
20-2 2ndPaper Near END SNS
20-1 2ndPaper END SNS
21-2 2ndLifter SNS
21-3 2ndFeed SNS
20-3 Cover Open 2nd SW
17-2 1stPaper Near END SNS
17-2 1stPaper Near END SNS
17-1 1stPaper END SNS
18-2 1stLifter SNS
18-3 1stFeed SNS
17-3 Cover Open 1st SW
13-2 Disposal toner box
12-4 Waste Toner Hole IC
12-3 Belt Hole IC
4-1 Cover Upper
15-3 Cover MPT
No10-1 TAG (K)
No10-2 TAG (Y)
No10-3 TAG (M)
No10-4 TAG (C)
No5-2
Stacker Full FU SNS
No5-3
Job off Paper Back End SNS
Job off Paper Back End SNS
No4-3 Cover Face Up
No4-2 Cover Left Upper
1-4 Exit SNS
12-2
Paper Slack SNS
12-1 Fuser Release SNS
32-2
Dup R SNS
Figure 5-1 Location of Switching Sensor
To Next Page
