Display
OUTPUT BIN
PUNCH
OFFSET
STAPLE MODE
STAPLE NUMBER
INVERT
Function
Printer face down
Finisher upper bin
Finisher lower bin
Punch on/off
Offset on/off
Staple mode off
Rear corner
Center corner
Front corner
Saddle stitch
Set the number of sheets to be stapled (0 to 50).
* When the staple mode is on, ÅgSTAPLE NUMBERÅh is
selectable between 2 and 50.
Invert on/off
Setting value
FACE DOWN
FINISHER UPPER BIN
FINISHER LOWER BIN
OFF
ON
OFF
ON
OFF
Rear
Center
Front
Saddle
0
OFF
ON
The settings shaded in are default settings.
* COLOR Setting
When COLOR is on, if [ONLINE] is pressed, the settings below will appear and the print
color-setting mode will be entered.
Press [ONLINE] to move the cursor to the color to be turned on or off.
Press [MENU+] or [MENU-] to turn the setting of each color on or off, respectively[OK to
add?].
Press [ENTER] to exit the print color-setting mode.
* FINISHER Setting
(1) When “FINISHER” is shown at the bottom of the display panel, press [ENTER].
(2) Press [MENU+] or [MENU-] until the setting item to be edited appears.
(3) Press [ENTER]; the set value will appear at the bottom of the panel.
Press [MENU+] or [MENU-] until the desired value appears. ([MENU+] increases the
value and [MENU-] decreases the value.)
(4) Press [BACK] to return to step (2) above. Press [BACK] again to return to step (1).
(5) Repeat steps (2) to (4) as necessary.
COLOR
Y:ON M:ON C:ON K:ON
4. Operations in section 2 will execute test printing at the set value that is set in Steps 2
to 3, by pressing the [ENTER] key when the state displays “PRINT EXECUTE” at the
bottom row of the display.
Press the [ENTER] key to stop test printing.
Print Test Pattern
Note
Pattern No.
0
1
2
3
4
5
6
7
Print pattern
None (blank page)
2 by 2
4 by 4
Horizontal line
Slanted line
Vertical line
Vertical band
Full
