Oki C9600 Service Manual

Oki Data CONFIDENTIAL
42930511TH Rev. 2 88 /
Table 4-1 Maintenance Tools
No. Quantity Purpose Remarks
1
2
3
4
5
6
8
No. 2-200
+ Magnetic Screw Driver
No. 3-100 Screw Driver
No. 5-200 Screw Driver
Digital Multimeter
Pliers
Portable Vacuum Cleaner
LED Head Cleaner
P/N 4PB4083-2248P001
1
1
1
1
1
1
1
2-2.5 mm screw
3-5 mm screw
LED Head Cleaner
7 1
Maintenance Tools
No. 1-100
+ Screw Driver
9
1
Cut-Sheet Film
(Maintenance)
42404301
10
1
Label
Paper Thickness
Sensor for
Adjustment
Transparency Sheet
11
- Micro-Driver
2.0mm
1
Paper Thickness
for Adjustment
High Voltage Probe
[Maintenance Tools ]
The tools necessary to replace the printed circuit board (PCB) and unit are indicated in Table 4-1.
