OKIDATA MICROLINE 320 - Disassembly;Reassembly Procedure; Printhead

3 – 3
Control/Power
supply board
Upper cover assy
Transformer assy
Operation panel board
Printhead
Printer unit
Driver board
3.3 Disassembly/Reassembly Procedure
This section explains the assembly replacement procedures according to the following disassembly
system.
Parts Layout
Figure 3-1 Printer unit
