OKIDATA MICROLINE 320 - Printer Configuration; Standard Printer Configuration

1 – 1
1. CONFIGURATION
1.1. Standard Printer Configuration
This printer consists of the following assemblies:
Figure 1-1 Configuration
Sheet guide assy
Platen knob
Access cover
assy
Upper cover
Control/Power supply assy
Traansformer assy
Pull-up roller assy
Operation panel assy
Main chassis assy
Driver board
