OKIDATA MICROLINE 320 - Connection Checks and Flowcharts

5 – 4
(5) Lubrication point
1. Ribbon feed gear Assy.
2. Space rack
Idle gear shaft (upper and lower)
PM-B (0.006±0.002g)
Space rack
Rack upper side
Approx. 30 (greasing range)
Planetary gear shaft
(upper and lower)
EM-30L-A
Drive gear shaft (upper and lower)
PM-B (0.006±0.002g)
Approx. 35 (greasing range)
EM-30L-A
