Olivetti d-Copia 5200MF User Manual

2KR/2KS
1-5-15
17. Remove the screw and then remove the
exposure lamp from mirror 1 frame.
18. Check or replace the exposure lamp and
then install the lamp.
19. Refit all the removed parts.
Figure 1-5-33
Mirror 1 frame
Mirror 1
frame
Screw
Exposure
lamp
Exposure lamp
Y111960-2 Service Manual
