2KR/2KS
2-3-3
YC6 1 +24VD O 24 V DC 24 V DC power output to ISM PWB
Connected
to the ISM
PWB
2 +24VD O 24 V DC 24 V DC power output to ISM PWB
3 +24VD O 24 V DC 24 V DC power output to ISM PWB
4 PGND - - Ground
5 PGND - - Ground
6 PGND - - Ground
7 SGND - - Ground
8 SGND - - Ground
9 SGND - - Ground
10 SGND - - Ground
11 +12VD O 12 V DC 12 V DC power output to ISM PWB
12 +5VD - - Not used
13 +3.3VD - - Not used
14 +3.3VD - - Not used
YC7
1 LIVE O 120 V AC
220-240 V AC
AC power output to CH
Connected
to the cas-
sette heater
2 NC - - Not used
3 NEUTRAL O 120 V AC
220-240 V AC
AC power output to CH
YC8 1 +24VDF O 24 V DC 24 V DC power output to paper feeder
Connected
to the paper
feeder, doc-
ument fin-
isher and
hard disk
2 +24VDF O 24 V DC 24 V DC power output to document finisher
3 +5VDF O 5 V DC 5 V DC power output to document finisher
4 P.GND - - Ground
5 F.GND - - Ground
6 P.GND - - Ground
7 +12V O 12 V DC 12 V DC power output to hard disk
8 GND - - Ground
9 GND - - Ground
10 +5VD O 5 V DC 5 V DC power output to hard disk
YC9 1 +12VD O 12 V DC 12 V DC power output to OPWB-M
Connected
to the main
operation
PWB
2 +5V O 5 V DC 5 V DC power output to OPWB-M
3 +5V O 5 V DC 5 V DC power output to OPWB-M
4 GND - - Ground
5 GND - - Ground
6 GND - - Ground
7 NC - - Not used
