2KR/2KS
2-3-4
YC10 1 SLEEP_N I 0/5 V DC SLEEP signal
Connected
to the main
PWB, DP
and engine
PWB
2 +5VDF O 5 V DC 5 V DC power output to DPDPWB
3 5V O 5 V DC 5 V DC power output to MPWB
4 5V O 5 V DC 5 V DC power output to MPWB
5 5V O 5 V DC 5 V DC power output to MPWB
6 5V O 5 V DC 5 V DC power output to MPWB
7 NC - - Not used
8 NC - - Not used
9 NC - - Not used
10 NC - - Not used
11 GND - - Ground
12 NC - - Not used
13 GND - - Ground
14 GND - - Ground
15 GND - - Ground
16 GND - - Ground
Connector Pin No. Signal I/O Voltage Description
Service Manual Y111960-2
