Olivetti d-Copia 5200MF User Manual

2KR/2KS
2-3-19
YC9 21 EXTBOEN O 0/3.3 V DC (pulse) EXTBOEN signal
Connected
to the inter-
face PWB
22 CFWEN0 O 0/3.3 V DC (pulse) CFWEN0 signal
23 EXTBDIR O 0/3.3 V DC (pulse) EXTBDIR signal
24 CFRST0 O 0/3.3 V DC CFRST0 signal
25 CF0CSN0 O 0/3.3 V DC (pulse) CF0CSN0 signal
26 CFWAITN0 I 0/3.3 V DC CFWAITN0 signal
27 CF0CSN1 O 0/3.3 V DC (pulse) CF0CSN1 signal
28 CF0CDET1 I 0/3.3 V DC CF0CDET1 signal
29 GND - - Ground
30 CF0CDET2 I 0/3.3 V DC CF0CDET2 signal
YC10 1 GND - - Ground
Connected
to the DP
2 GND - - Ground
3 3.3V O 3.3 V DC 3.3 V DC power output to DPRPWB
4 3.3V O 3.3 V DC 3.3 V DC power output to DPRPWB
5 3.3V O 3.3 V DC 3.3 V DC power output to DPRPWB
6 3.3V O 3.3 V DC 3.3 V DC power output to DPRPWB
7 VCLKB I 0/3.3 V DC (pulse) DPRPWB clock signal
8 VSYNCB I 0/3.3 V DC (pulse) DPRPWB VSYNCB signal
9 HSYNCB I 0/3.3 V DC (pulse) DPRPWB HSYNCB signal
10 MREB I 0/3.3 V DC (pulse) DPRPWB MREB signal
11 GND - - Ground
12 DRB0 I 0/3.3 V DC (pulse) Image data signal
13 DRB1 I 0/3.3 V DC (pulse) Image data signal
14 DRB2 I 0/3.3 V DC (pulse) Image data signal
15 DRB3 I 0/3.3 V DC (pulse) Image data signal
16 DRB4 I 0/3.3 V DC (pulse) Image data signal
17 DRB5 I 0/3.3 V DC (pulse) Image data signal
18 DRB6 I 0/3.3 V DC (pulse) Image data signal
19 DRB7 I 0/3.3 V DC (pulse) Image data signal
20 GND - - Ground
21 DGB0 I 0/3.3 V DC (pulse) Image data signal
22 DGB1 I 0/3.3 V DC (pulse) Image data signal
23 DGB2 I 0/3.3 V DC (pulse) Image data signal
24 DGB3 I 0/3.3 V DC (pulse) Image data signal
25 DGB4 I 0/3.3 V DC (pulse) Image data signal
26 DGB5 I 0/3.3 V DC (pulse) Image data signal
27 DGB6 I 0/3.3 V DC (pulse) Image data signal
28 DGB7 I 0/3.3 V DC (pulse) Image data signal
29 GND - - Ground
30 DBB0 I 0/3.3 V DC (pulse) Image data signal
31 DBB1 I 0/3.3 V DC (pulse) Image data signal
32 DBB2 I 0/3.3 V DC (pulse) Image data signal
33 DBB3 I 0/3.3 V DC (pulse) Image data signal
34 DBB4 I 0/3.3 V DC (pulse) Image data signal
35 DBB5 I 0/3.3 V DC (pulse) Image data signal
Connector Pin No. Signal I/O Voltage Description
Y111960-2 Service Manual
