2KR/2KS
2-3-20
YC10 36 DBB6 I 0/3.3 V DC (pulse) Image data signal
Connected
to the
optional DP
37 DBB7 I 0/3.3 V DC (pulse) Image data signal
38
TWS_SCM_HALF O 0/3.3 V DC DPRPWB control signal
39 RES_SLEEP O 0/3.3 V DC DPRPWB control signal
40 TWS_DET1 I 0/3.3 V DC DPRPWB control signal
41 GND - - Ground
42 LA2 O 0/3.3 V DC (pulse) Address bus signal
43 LA3 O 0/3.3 V DC (pulse) Address bus signal
44 LA4 O 0/3.3 V DC (pulse) Address bus signal
45 LA5 O 0/3.3 V DC (pulse) Address bus signal
46 LA6 O 0/3.3 V DC (pulse) Address bus signal
47 LA7 O 0/3.3 V DC (pulse) Address bus signal
48 LA8 O 0/3.3 V DC (pulse) Address bus signal
49 LA9 O 0/3.3 V DC (pulse) Address bus signal
50 LA10 O 0/3.3 V DC (pulse) Address bus signal
51 LA11 O 0/3.3 V DC (pulse) Address bus signal
52 LA12 O 0/3.3 V DC (pulse) Address bus signal
53 LA13 O 0/3.3 V DC (pulse) Address bus signal
54 LA14 O 0/3.3 V DC (pulse) Address bus signal
55 LA15 O 0/3.3 V DC (pulse) Address bus signal
56 LA16 O 0/3.3 V DC (pulse) Address bus signal
57 LA17 O 0/3.3 V DC (pulse) Address bus signal
58 GND - - Ground
59 LD0 I/O 0/3.3 V DC (pulse) Data bus signal
60 LD1 I/O 0/3.3 V DC (pulse) Data bus signal
61 LD2 I/O 0/3.3 V DC (pulse) Data bus signal
62 LD3 I/O 0/3.3 V DC (pulse) Data bus signal
63 LD4 I/O 0/3.3 V DC (pulse) Data bus signal
64 LD5 I/O 0/3.3 V DC (pulse) Data bus signal
65 LD6 I/O 0/3.3 V DC (pulse) Data bus signal
66 LD7 I/O 0/3.3 V DC (pulse) Data bus signal
67 GND - - Ground
68 INT I 0/3.3 V DC DPRPWB control signal
69 RESETZ O 0/3.3 V DC DPRPWB control signal
70 GND - - Ground
71 CEZ O 0/3.3 V DC (pulse) DPRPWB control signal
72 WEZ O 0/3.3 V DC (pulse) DPRPWB control signal
73 OEZ O 0/3.3 V DC (pulse) DPRPWB control signal
74 SCLKIN O 0/3.3 V DC (pulse) DPRPWB clock signal
75 3.3V O 3.3 V DC 3.3 V DC power output to DPRPWB
76 3.3V O 3.3 V DC 3.3 V DC power output to DPRPWB
77 3.3V O 3.3 V DC 3.3 V DC power output to DPRPWB
78 3.3V O 3.3 V DC 3.3 V DC power output to DPRPWB
79 GND - - Ground
80 GND - - Ground
Connector Pin No. Signal I/O Voltage Description
Service Manual Y111960-2
