10-014357-01EN, Rev. 2, January 2022
Chapter 122
72DL PLUS (right side)
14 USB A connector
15 USB Mini-B connector
16 USB A connector
17 Micro HDMI connector
72DL PLUS (rear)
18 Battery compartment cover
Table 3 72DL PLUS precision thickness gauge components (continued)
Component key 72DL PLUS—All models
⑭⑮⑯⑰
⑱
