10-014357-01EN, Rev. 2, January 2022
Overview 23
2. Overview
The 72DL PLUS precision thickness gauge has a complement of connections intended
to maximize the usability of the instrument. This chapter describes the location of the
controls, connectors, and attachment points on the 72DL PLUS gauge.
2.1 External Connectors
The external connectors are located at the top of the 72DL PLUS gauge (Figure 2-1 on
page 23).
Figure 2-1 External connectors location
DC power connector
LEMO connectors
BNC connector
19-pin connector
