Overview 27
Figure 2-7 Cover thumb screw
2.3 Data Port
The data port contains the 72DL PLUS digital I/O connectors (Figure 2-8 on page 27).
Figure 2-8 Data port connectors
USB A connector
USB Mini-B connector
Micro HDMI connector
USB A connector
