10-014357-01EN, Rev. 2, January 2022
Package Contents 21
Table 3 72DL PLUS precision thickness gauge components
Component key 72DL PLUS—All models
72DL PLUS (front)
1Adjustment knob
2 User interface display
3Home key
4 Save/Send key
5 Calibration key
6 Play/Pause key
7Function key
8Power indicator
9Power key
72DL PLUS (top)
10 Transducer receive only
connector
11 Transducer transmit/receive
connector
12 Transducer high-frequency
transmit/receive connector
(high frequency model only)
13 19-pin accessory connector
14 DC power connector
(12 VDC)
