10-014357-01EN, Rev. 2, January 2022
Labels and Symbols 3
To avoid the risk of electric shock, do not touch the inner conductor of the BNC or
LEMO connectors. Up to 400 V can be present on the inner conductor. The warning
symbol between the Transmit/Receive (T/R) and the Receive (R) connectors shown in
the figure below warns of this electric shock risk.
The WEEE symbol indicates that the product must not be
disposed of as unsorted municipal waste, but should be
collected separately.
The DC connector polarity symbol.
Table 1 Content of the rating label (continued)
Warning symbols
LEMO connectors
BNC connector
