103
EN
Shooting
2
Filming High-Speed Movies
Film at high frame rates. Movies are lmed at 120 fps and play back at 60 fps.
Stretching playback to double the recording time (as is the case when 60p is selected
as the playback frame rate) lets you view in slow motion movements that in real life
took only the blink of an eye.
A high-speed movie option can be included in the movie image quality menu. Your
choice of playback frame rate determines the playback speed multiplier.
Changes to settings are re ected in the movie quality icon as shown.
Frame size
FHD Full HD (1920 × 1080)
Movie type
HS High speed (120 fps)
Playback frame rate
60p 60p: 59.94 fps; plays back at 0.5× speed
50p 50p: 50.00 fps; plays back at 0.42× speed
30p 30p: 29.97 fps; plays back at 0.25× speed
25p 25p: 25.00 fps; plays back at 0.21× speed
24p 24p: 23.98 fps; plays back at 0.2× speed
1
Select (high-speed movie recording).
To use current settings, press the Q button. The camera will exit the menu with the
current options selected.
2
To edit current settings, press the INFO button in Step 1.
This places the cursor in the list of high-speed movie options.
3
Choose the playback frame rate.
• Use FG on the arrow pad to highlight the desired playback frame rate.
4
Press the Q button to select the highlighted option and exit.
Focus, exposure, and white balance lock during recording.
Sound is not recorded.
The picture angle is slightly reduced.
Aperture, shutter speed, exposure compensation, and ISO sensitivity cannot be changed
during recording.
Time codes cannot be recorded or displayed.
Brightness may change if zoom is adjusted during recording.
Individual movies can be up to 4 GB in size.
High-speed movie recording is not available while the camera is connected to an HDMI
device.
• [n Image Stabilizer] > [M-IS1] is not available.
• [Movie H] cannot be used.
[i-Enhance], [e-Portrait], and art lter picture modes are not available.
• [Gradation] is xed at [Gradation Normal].
High-speed movie recording is not available during remote photography when the camera
is connected to a smartphone.
