Olympus E-M1 Mark III User Manual

72 EN
Shooting
2
Choosing a Focus Target (AF Target Point)
The frame showing the location of the focus point is referred to as the “AF target”. You
can position the target over your subject. At default settings, the multi selector is used
to position the AF target.
1
Use the multi selector to position the AF target.
• The target can also be positioned using the arrow pad.
Pressing FGHI buttons displays the AF target.
Multi selector
• The AF target is displayed at the start of the operation.
• To select the center AF target, press the multi selector
or press and hold the Q button.
• You can choose whether AF-target selection “wraps
around” the edges of the display (P. 208).
M
100 %
AF target
2
Take pictures.
• The AF-target selection display will clear from the monitor when the shutter button is
pressed halfway.
• The AF frame is displayed in place of the selected AF target.
• If [N] is assigned to a control using [Button Function] (P. 116), you can press the
control and then use the arrow pad or multi selector to choose the AF target.
• You can reposition the AF target during focusing when [C-AF] or [C-AFb] is selected in
still photography mode.
• You can also reposition the AF target during movie recording.
• The size and number of the AF target changes depending on the [Digital Tele-converter]
(P. 143), [Aspect] (P. 98), and group target (P. 69) settings.
%
• When [On] is selected for [AF Targeting Pad] (P. 183), you can reposition the AF target
using monitor touch controls while framing your subject in the viewfi nder.

Olympus E-M1 Mark III Specifications

General

Megapixel	20.4 MP
Camera type	MILC
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	- \
Image formats supported	JPEG, RAW
Supported aspect ratios	4:3
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.4 x 13 mm
Still image resolution(s)	5184 x 3888, 1024 x 768
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.15 m
Normal focusing range (tele)	- m
Auto Focus (AF) points selection	Auto, Manual
Filter size	72 mm
Digital zoom	- x
Focal length range	12 - 100 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	4
Minimum aperture number	22
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	17/11
Maximum focal length (35mm film equiv)	200 mm
Minimum focal length (35mm film equiv)	24 mm
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
HDMI connector type	Micro
Headphone connectivity	3.5 mm
Magnification	1.48 x
Viewfinder type	Electronic
Display diagonal	3 \
Display resolution	1037000 dot
Display aspect ratio	3:2
Memory slots	2
Compatible memory cards	SD, SDHC, SDXC
Audio system	stereo
Audio formats supported	PCM
Cables included	USB
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVC, H.264, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLH-1
Battery life (max)	1.4 h
Battery life (CIPA standard)	420 shots
ISO sensitivity	64, 100, 200, 6400, 25600
ISO sensitivity (max)	25600
ISO sensitivity (min)	64
Product color	Black
Freezeproof up to	-10 °C
International Protection (IP) code	IPX1
Eye relief	21 mm
Scene modes	Portrait, Underwater
Image editing	Trimming
Photo effects	Black&White, Vivid
White balance	Auto, Custom modes
Shooting modes	Auto
Camera playback	Movie, Single image
Self-timer delay	- s
Camera file system	DCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)	-4 - 2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	504 g
Lens length	116.5 mm
Lens weight	561 g
Lens diameter	77.5 mm
Weight (including battery)	580 g
