Preparation
1
HLD-9 Power Battery Holder
An optional HLD-9 battery holder can be used to power the camera for extended
periods. You can assign functions to the arrow pad and B-Fn button using the camera
[Button Function] options. The optional AC adapter can be used with the HLD-9.
Make sure to turn the camera off when attaching and removing the holder.
Part names
Front dial
Shutter button
Removal knob
Arrow pad
Q button
Vertical shooting lock
Rear dial
AC terminal cover
B-Fn2 button
B-Fn1 button
Attaching the holder
Remove the PBH cover (a) on the
bottom of the camera before attaching
the HLD-9. Once attached, make sure
the HLD-9 removal knob is tightly
secured. Make sure to attach the PHB
cover to the camera when not using
the HLD-9.
a
a
Store the PBH cover (a) in the HLD-9.
Loading the battery
Use BLH-1 battery. Once you load the battery, make sure to lock the battery cover.
1
2
Direction indicating mark
%
• The monitor battery-level indicator (P. 32) shows
when the camera is powered by the battery in the HLD-9.
PBH
