52
EN
Shooting
2
Long Exposures (
B
: Bulb/Time)
Select this mode to leave the shutter open for a long exposure. You can preview the
photo in live view and end the exposure when the desired results have been achieved.
Use when long exposures are required, for example when photographing night scenes
or reworks.
“Bulb” and “Live Bulb” Photography
The shutter remains open while the shutter button is pressed. Releasing the button ends the
exposure.
The amount of light entering the camera increases the longer the shutter is open.
When live bulb photography is selected, you can choose how often the camera updates
the live view display during the exposure.
“Time” and “Live Time” Photography
The exposure begins when the shutter button is pressed all the way down. To end the
exposure, press the shutter button all the way down a second time.
The amount of light entering the camera increases the longer the shutter is open.
When live time photography is selected, you can choose how often the camera updates
the live view display during the exposure.
1
Rotate the mode dial to
B
.
2
Select bulb or time photography.
At default settings, the selection is made with the rear
dial.
3
Press the MENU button.
You will be prompted to choose the interval at which the
preview is updated.
BULB F5.6
ISO
200
1023
1:02:03
B
30
p
30
p
4K
S-IS OFFS-IS OFF
YFYF
100
%
G
Bulb or time photography
4
Highlight an interval using FG on the arrow pad.
5
Press the
Q
button to select the highlighted option.
The menus will be displayed.
ISO L64 ~
ISO 400 ~
ISO 800 ~
ISO 1600 ~
100
%
SetBack
Live Bulb
1sec
Display Count
24 times
19 times
14 times
9 times
6
Press the MENU button to exit the menus.
If an option other than [Off] is selected, [LIVE BULB] or [LIVE TIME] will appear in the
display.
