Olympus E-M1 Mark III User Manual

319 EN
Information
7
White balance
Mode setting Auto/Preset WB (7 settings)/Customized WB/One-touch WB (camera can
store up to 4 settings)
Recording
Memory SD, SDHC and SDXC
UHS-II compatible (Slot 1 only)
Recording system Digital recording, JPEG (DCF2.0), RAW Data
Applicable standards Exif 2.3, Digital Print Order Format (DPOF)
Sound with still pictures Wave format
Movie MPEG-4 AVC/H.264
Audio Stereo linear PCM, 16 bit; sampling frequency 48 kHz (wave format)
Stereo linear PCM, 24 bit; sampling frequency 96 kHz (wave format)
Playback
Display format Single-frame playback/Close-up playback/Index display/Calendar display
Drive
Drive mode Single frame; sequential; anti-shock; silent; Pro Capture; self-timer;
High Res Shot
Sequential shooting
Up to 15 fps (T)
Up to 60 fps (♥T, p)
Self-timer Operation time: 12 sec./2 sec./Customized
Energy saving function Switch to sleep mode: 1 minute, Power OFF: 4 hours
(This function can be customized.)
Flash
Flash control mode TTL-AUTO (TTL pre-fl ash mode)/MANUAL
X-Sync. 1/250 s or slower
Wireless LAN
Compatible standard IEEE 802.11a/b/g/n/ac *
Bluetooth
®
Compatible standard Bluetooth Version 4.2 BLE
External connector
USB (Type C); HDMI micro connector (type D); external fl ash; remote cable (ø2.5 mm mini-jack);
microphone jack (ø3.5 mm stereo mini-jack); headphone jack (ø3.5 mm stereo mini-jack)
Power supply
Battery Lithium-ion Battery ×1
Dimensions/weight
Dimensions Approx. 134.1 mm (W) × 90.9 mm (H) × 68.9 mm (D) (5.3" × 3.6" × 2.7")
(excluding protrusions)
Weight Approx. 580 g (1.3 Ib.) (including battery and memory card)
Operating environment
Temperature −10 °C - 40 °C (14 °F - 104 °F) (operation)/ −20 °C - 60 °C (−4 °F - 140 °F)
(storage)
Humidity 30% - 90% (operation)/10% - 90% (storage)
Water resistance Type: IEC Standard publication 60529 IPX1 (applies if camera is used
with Olympus water-resistant lens)
* Note that cameras have been developed in line with the different standards of the countries.

Olympus E-M1 Mark III Specifications

General

Megapixel	20.4 MP
Camera type	MILC
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.8 MP
Image sensor size	- \
Image formats supported	JPEG, RAW
Supported aspect ratios	4:3
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.4 x 13 mm
Still image resolution(s)	5184 x 3888, 1024 x 768
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	121
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.15 m
Normal focusing range (tele)	- m
Auto Focus (AF) points selection	Auto, Manual
Filter size	72 mm
Digital zoom	- x
Focal length range	12 - 100 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	4
Minimum aperture number	22
Number of diaphragm blades	7
Number of aspheric elements	3
Lens structure (elements/groups)	17/11
Maximum focal length (35mm film equiv)	200 mm
Minimum focal length (35mm film equiv)	24 mm
PictBridge	-
USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector	USB Type-C
Headphone outputs	1
HDMI connector type	Micro
Headphone connectivity	3.5 mm
Magnification	1.48 x
Viewfinder type	Electronic
Display diagonal	3 \
Display resolution	1037000 dot
Display aspect ratio	3:2
Memory slots	2
Compatible memory cards	SD, SDHC, SDXC
Audio system	stereo
Audio formats supported	PCM
Cables included	USB
Video resolutions	1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Video recording time	29 min
Video formats supported	AVC, H.264, MOV, MPEG4
Maximum video resolution	4096 x 2160 pixels
Resolution at capture speed	1280x720@24fps, 1280x720@25fps, 1280x720@30fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@25fps, 3840x2160@30fps, 4096x2160@24fps
Flash modes	Auto, Fill-in, Flash off, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed	1/250 s
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/2, 1/3, 1 EV step)
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Camera shutter type	Electronic, Mechanical
Fastest camera shutter speed	1/32000 s
Slowest camera shutter speed	60 s
Battery type	BLH-1
Battery life (max)	1.4 h
Battery life (CIPA standard)	420 shots
ISO sensitivity	64, 100, 200, 6400, 25600
ISO sensitivity (max)	25600
ISO sensitivity (min)	64
Product color	Black
Freezeproof up to	-10 °C
International Protection (IP) code	IPX1
Eye relief	21 mm
Scene modes	Portrait, Underwater
Image editing	Trimming
Photo effects	Black&White, Vivid
White balance	Auto, Custom modes
Shooting modes	Auto
Camera playback	Movie, Single image
Self-timer delay	- s
Camera file system	DCF 2.0, DPOF, Exif 2.31
Diopter adjustment (D-D)	-4 - 2
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2

Weight and Dimensions

Depth	68.9 mm
Width	134.1 mm
Height	90.9 mm
Weight	504 g
Lens length	116.5 mm
Lens weight	561 g
Lens diameter	77.5 mm
Weight (including battery)	580 g
