Instrument Overview
19
On/off switch ( )
This switch is used to turn on and off the TomoScan FOCUS LT.
POWER CORD PROVIDES
AC (~) POWER DISCONNECT
This marking on the back panel indicates that the internal AC power supply is not
disconnected from the AC source when the unit is turned off using the front panel
on/off switch ( ). To disconnect the AC source, first disconnect the power cord from
the AC outlet, and then disconnect the power cord from the back of the instrument.
Failure to do so can cause electric shocks.
Handles
Two handles are located on each side of the front panel. They are used to disassemble
and reassemble the unit.
The front panel handles should not be used to carry the TomoScan FOCUS LT.
Because the handles were not designed to transport the instrument, they may break
off.
Front panel protective bumper
The rubber bumper shown in Figure 1-2 on page 20 protects the front panel
components.
