CP TD1 User Manual
66 OMICRON
Phase angle ϕ
Impedance Z
Inductance Lx (equivalent serial circuit)
Quality factor QF
Power P, Q, S (selective)
Table 7-9: Phase angle ϕ
Range Typical accuracy Conditions
-90 °...+90 ° error < 0.01 ° Vtest = 300 V...10 kV
Table 7-10: Impedance Z
Range Typical accuracy Conditions
1k
Ω...1200 MΩ error < 0.5 % of reading Vtest = 300 V...10 kV
Table 7-11: Inductance Lx
Range Typical accuracy
1 H...1000 kH error < 0.3 % of reading
Table 7-12: Quality factor QF
Range Typical accuracy
0...1000 error < 0.5 % of reading + 0.2 %
> 1000 error < 5 % of reading
Table 7-13: Power P, Q, S
Range Typical accuracy
0...3.6 kW error < 0.5 % of reading + 1 mW
0...3.6 kVAR error < 0.5 % of reading + 1 mVAR
0...3.6 kVA error < 0.5 % of reading + 1 mVA
