OMICRON 29
Application
If the CPC 100 or CPC 80 is the Control Device:
12.If the PE connection and the galvanic ground connection of the power supply are both intact and the
error message still appears, you can deactivate the Ground check and continue testing.
Note: After the CPC 100 or CPC 80 has been rebooted, the "Disable ground check" check box is cleared
for safety reasons.
3.3 Measurement
The CP TD1 can be either controlled via one of the Control Devices directly or via Primary Test Manager
(PTM) in combination with a Control Device.
For a detailed description of the user interface of the respective Control Device or Primary Test Manager
and how to start measurements using the respective option please refer to the following documents:
3.4 Disconnection
1. Switch off the high voltage with start/stop push-button.
2. Press the Emergency Stop button on the Control Device’s front panel.
WARNING
Death or severe injury caused by high voltage or current possible
If the Ground check is disabled, the operator is fully responsible for any hazard that might
occur due to improper grounding.
► Only deactivate the Ground check if you are completely sure that the measurement
equipment is properly grounded via PE and grounding terminal connections.
► Make sure that the grounding terminal connections stay intact during the whole
measurement procedure. If necessary, block the area to prevent unaware people from
stumbling over the grounding cables, possibly disconnecting them inadvertently.
Option Document
CPC 100 CPC 100 User Manual
CPC 100 Reference Manual
CPC 100 + PTM CPC 100 PTM User Manual
CPC 80 CPC 80 User Manual
TESTRANO 600 TESTRANO 600 User Manual
TESTRANO 600 + PTM TESTRANO 600 User Manual
WARNING
Death or severe injury caused by high voltage or current possible
The green warning light indicates that the outputs of the Control Device are not activated.
► Even if you switched off the Control Device, wait until the red warning light is fully
extinguished. As long as this warning light is lit, there is still voltage potential on the
output.
