OMICRON 67
Technical data
7.2 Mechanical data
7.3 Environmental Conditions
Table 7-14: Mechanical data
Device(s) / accessories Weight Dimensions (W x H x D)
CP TD1
Test se t 25 kg / 55.2 lb
450 x 330 x 220 mm
17.7 x 13 x 8.7 inches
without handles
Test set & case
1
1. Case = robust case, IP22
38.1 kg / 84 lb
700 x 500 x 420 mm
27.5 x 19.7 x 16.5 inches
Cables and accessories
Equipment 16.6 kg / 36.6 lb
Equipment & case
1
26.6 kg / 58.7 lb
680 x 450 x 420 mm
26.8 x 17.7 x 16.5 inches
Equipment trolley
Equipment 14.5 kg / 32 lb
Equipment & carton 18.9 kg / 41.7 lb
590 x 750 x 370 mm
23.2 x 29.2 x 14.6 inches
CP TD1, CPC 100,
equipment & trolley
Equipment 85 kg / 187.5 lb
750 x 1050 x 600 mm
29.5 x 41.3 x 23.6 inches
Equipment & packing 125 kg / 275.8 lb
CP TD1,
TESTRANO 600,
equipment & trolley
Equipment 85 kg / 187.5 lb
750 x 1050 x 600 mm
29.5 x 41.3 x 23.6 inches
Equipment & packing 125 kg / 275.8 lb
Table 7-15: Climate
Characteristic Rating
Temperature
Operating –10…+55 ºC / +14…+131 ºF
Storage and
transportation
–20…+70 ºC / –4…+158 ºF
Max. altitude 2000 m
Relative humidity 5…95 %; no condensation, tested according to IEC 60068-2-78
Table 7-16: Noise Immunity
Characteristic Rating
Noise Immunity Electrostatic: 15 mA induced noise into any test lead without losing measurement
accuracy at maximum interference to specimen current of 20:1
Electromagnetic: 500 µT, at 60 Hz in any direction
