6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
(iii) Holding Register Number List (Monitor)
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
1001h
Output Frequency
Monitor
d001(HIG
H)
R 0 to 40000(100000) 0.01 [Hz] 5-1
1002h
d001
(LOW)
1003h Output Current Monitor d002 R 0 to 65530 0.01 [A] 5-1
1004h
Rotation Direction
Monitor
d003 R
0: Stop
1: Forward
2: Reverse
− 5-2
1005h
PID Feedback Value
Monitor
d004
(HIGH)
R 0 to 1000000 0.1 5-2
1006h
d004
(LOW)
1007h
Multi-function Input
Monitor
d005 R
2
0
: Terminal S1 to
2
6
: Terminal S7/EB
Bit 5-3
1008h
Multi-function Output
Monitor
d006 R
2
0
: Terminal P1/EDM
to 2
1
: Terminal P2
2
6
: Relay output terminal
Bit 5-3
1009h
Output Frequency
Monitor (after
conversion)
d007
(HIGH)
R 0 to 4000000(10000000) 0.01 5-4
100Ah
d007
(LOW)
100Bh
Real Frequency Monitor
d008
(HIGH)
R
−100000 to +100000 0.01 [Hz] 5-5
100Ch
d008
(LOW)
R
100Dh
Torque Reference
Monitor
d009 R −200 to +200 1 [%] 5-5
100Eh Torque Bias Monitor d010 R −200 to +200 1 [%] 5-6
100Fh Reserved −−− −−
1010h Output Torque Monitor d012 R −200 to +200 1 [%] 5-6
1011h Output Voltage Monitor d013 R 0 to 6000 0.1 [V] 5-6
1012h Input Power Monitor d014 R 0 to 9999 0.1 [kW] 5-7
1013h
Integrated Power Monitor
d015
(HIGH)
R 0 to 9999000 − 5-7
1014h
d015
(LOW)
1015h
Total RUN Time Monitor
d016
(HIGH)
R 0 to 999000 1 [h] 5-8
1016h
d016
(LOW)
1017h
Power ON Time Monitor
d017
(HIGH)
R 0 to 999000 1 [h] 5-8
1018h
d017
(LOW)
1019h Fin Temperature Monitor d018 R −200 to 1500 0.1 [°C] 5-8
