6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
101Ah
to
101Ch
Reserved −−− −−
101Dh
Life Assessment Monitor d022 R
2
0
: Capacitor on main circuit
board
2
1
: Cooling fan
Bit 5-9
101Eh
to
1025h
Reserved −−− −−
1026h DC Voltage Monitor d102 R 0 to 10000 0.1 [V] 5-12
1027h
Regenerative Braking
Load Rate Monitor
d103 R 0 to 1000 0.1 [%] 5-12
1028h
Electronic Thermal Load
Rate Monitor
d104 R 0 to 1000 0.1 [%] 5-12
1029h
to
1035h
Reserved −−− −−
1036h
Position Command
Monitor
d029
(HIGH)
R
−268435455 to 268435455 1 5-9
1037h
d029
(LOW)
R
1038h
Current Position Monitor
d030
(HIGH)
R
−268435455 to 268435455 1 5-9
1039h
d030
(LOW)
R
103Ah
to
1056h
Reserved −−− −−
1057h Inverter Mode Monitor d060 R
0: I-C (IM load heavy)
1: I-V (IM load light)
2: H-I (IM power supply harmonics)
− 5-10
1058h
to
1102h
Not used −−Inaccessible −−
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
