6-38
6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
(iv) Holding Register Number List (Group F)
(v) Holding Register Number List (Groups A, b, C, H and P)
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
1103h
Acceleration Time
Setting 1
F002
(HIGH)
R/W 1 to 360000 0.01 [s]
5-24
1104h
F002
(LOW)
1105h
Deceleration Time
Setting 1
F003
(HIGH)
R/W 1 to 360000 0.01 [s]
1106h
F003
(LOW)
1107h RUN Direction Selection F004 R/W
0: Forward
1: Reverse
− 5-23
1108h
to
1200h
Not used −−Inaccessible −−
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
1201h
Frequency Reference
Selection 1
A001 R/W
00: Volume
01: Control circuit terminal
block
02: Digital Operator
03: Modbus communication
(Modbus-RTU)
04: Optional board
06: Pulse train frequency
07: Do not set.
10: Operation function
output
− 5-15
1202h
RUN Command
Selection 1
*1
A002 R/W
01: Control circuit terminal
block
02: Digital Operator
03: Modbus communication
(Modbus-RTU)
04: Optional board
− 5-22
1203h Base Frequency 1 A003 R/W
300 to Maximum Frequency 1 0.1 [Hz] 5-26
1204h Maximum Frequency 1 A004 R/W
Base Frequency 1 to
4000 (10000)
0.1 [Hz] 5-28
1205h FV/FI Selection A005 R/W
00: Switch between FV/FI
02: Switch between FV/
volume
03: Switch between FI/
volume
− 5-38
1206h
to
120Ah
Reserved −−− − −
