Omron 3G3MX2 - Page 344

6-41
6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
1239h Jogging Stop Selection A039 R/W
00: Free run on jogging
stop/Disabled in
operation
01: Deceleration stop on
jogging stop/Disabled in
operation
02: Injection braking on
jogging stop/Disabled in
operation
03: Free run on jogging
stop/Enabled in
operation
04: Deceleration stop on
jogging stop/Enabled in
operation
05: DC injection braking on
jogging stop/Enabled in
operation
− 5-59
123Ah Reserved −−− − −
123Bh Torque Boost Selection 1 A041 R/W
00: Manual torque boost
01: Automatic torque boost
−
5-49
123Ch
Manual Torque Boost
Voltage 1
A042 R/W 0 to 200 0.1 [%]
123Dh
Manual Torque Boost
Frequency 1
A043 R/W 0 to 500 0.1 [%]
123Eh Control Method 1 A044 R/W
00: Constant torque
characteristics
01: Reduced torque
characteristics
02: Free V/f setting
03: Sensorless vector
control (heavy load only)
−
5-46
5-144
123Fh Output Voltage Gain 1 A045 R/W 20 to 100 1 [%] 5-72
1240h
Automatic Torque Boost
Voltage Compensation
Gain 1
A046 R/W 0 to 255 1 [%]
5-49
1241h
Automatic Torque Boost
Slip Compensation Gain 1
A047 R/W 0 to 255 1 [%]
1242h
to
1244h
Reserved −−− − −
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
