6-42
6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
1245h
Internal DC Injection
Braking Selection
A051 R/W
00: Disabled
01: Enabled
02: Enabled (Operates only
on set frequencies.)
−
5-135
1246h
Internal DC Injection
Braking Frequency
A052 R/W 0 to 6000 0.01 [Hz]
1247h
DC Injection Braking
Delay Time
A053 R/W 0 to 50 0.1 [s]
1248h
DC Injection Braking
Power
A054 R/W 0 to 100 1 [%]
1249h
DC Injection Braking
Time
A055 R/W 0 to 600 0.1 [s]
124Ah
DC Injection Braking
Edge/Level Selection
A056 R/W
00: Edge operation
01: Level operation
−
124Bh
Startup DC Injection
Braking Power
A057 R/W 0 to 100 1 [%]
124Ch
Startup Internal DC
Injection Braking Time
A058 R/W 0 to 600 0.1 [s]
5-135
124Dh
DC Injection Braking
Carrier Frequency
A059 R/W 20 to 150 (100) 0.1 [kHz]
124Eh Reserved −−− − −
124Fh
Frequency Upper Limit 1
A061
(HIGH)
R/W
0
Frequency Lower Limit 1 to
Maximum Frequency 1
0.01 [Hz] 5-60
1250h
A061
(LOW)
R/W
1251h
Frequency Lower Limit 1
A062
(HIGH)
R/W
0
Starting Frequency to
Frequency Upper Limit 1
0.01 [Hz] 5-60
1252h
A062
(LOW)
R/W
1253h
Jump Frequency 1
A063
(HIGH)
R/W
0 to 40000 (100000) 0.01 [Hz]
5-61
1254h
A063
(LOW)
R/W
1255h Jump Frequency Width 1 A064 R/W 0 to 1000 (10000) 0.01 [Hz]
1256h
Jump Frequency 2
A065
(HIGH)
R/W
0 to 40000 (100000) 0.01 [Hz]
1257h
A065
(LOW)
R/W
1258h Jump Frequency Width 2 A066 R/W 0 to 1000 (10000) 0.01 [Hz]
1259h
Jump Frequency 3
A067
(HIGH)
R/W
0 to 40000 (100000) 0.01 [Hz]
125Ah
A067
(LOW)
R/W
125Bh Jump Frequency Width 3 A068 R/W 0 to 1000 (10000) 0.01 [Hz]
125Ch
Acceleration Stop
Frequency
A069
(HIGH)
R/W
0 to 40000 (10000) 0.01 [Hz]
5-62
125Dh
A069
(LOW)
R/W
125Eh Acceleration Stop Time A070 R/W 0 to 600 0.1 [s]
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
