6-45
6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
12A7h
to
12AEh
Reserved −−− − −
12AFh
Operation Frequency
Selection 1
A141 R/W
00: Digital Operator
01: Volume
02: FV (voltage) input
03: FI (current) input
04: Modbus communication
(Modbus-RTU)
05: Optional board
07: Pulse train frequency
−
5-70
12B0h
Operation Frequency
Selection 2
A142 R/W
00: Digital Operator
01: Volume
02: FV (voltage) input
03: FI (current) input
04: Modbus communication
(Modbus-RTU)
05: Optional board
07: Pulse train frequency
−
12B1h
Operation Function
Operator Selection
A143 R/W
00: Addition (A141 + A142)
01: Subtraction (A141 −
A142)
02: Multiplication (A141 ×
A142)
−
12B2h Reserved −−− − −
12B3h
Frequency Addition
Amount Setting
A145
(HIGH)
R/W
0 to 40000 (100000) 0.01 [Hz]
5-71
12B4h
A145
(LOW)
R/W
12B5h
Frequency Addition Sign
Selection
A146 R/W
00: Frequency reference +
A145
01: Frequency reference −
A145
−
12B6h
to
12B8h
Reserved −−− − −
12B9h
EL-S Shape Acceleration
Curve Ratio 1
A150 R/W 0 to 50 1 [%]
5-68
12BAh
EL-S Shape Acceleration
Curve Ratio 2
A151 R/W 0 to 50 1 [%]
12BBh
EL-S Shape Deceleration
Curve Ratio 1
A152 R/W 0 to 50 1 [%]
12BCh
EL-S Shape Deceleration
Curve Ratio 2
A153 R/W 0 to 50 1 [%]
12BDh
Deceleration Stop
Frequency
A154
(HIGH)
R/W 0 to 40000 (100000) 0.01 [Hz]
5-62
12BEh
A154
(LOW)
12BFh Deceleration Stop Time A155 R/W 0 to 600 0.1 [s]
12C0h
PID Sleep Function
Operation Level
A156
(HIGH)
R/W 0 to 40000 (100000) 0.01 [Hz]
5-73 12C1h
A156
(LOW)
12C2h
PID Sleep Operation
Delay Time
A157 R/W 0 to 255 0.1 [s]
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
