Omron 3G3MX2 - Page 354

6-51
6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
135Dh
Usage Rate of
Regenerative Braking
b090 R/W 0 to 1000 0.1 [%] 5-141
135Eh Stop Selection b091 R/W
00: Deceleration stop
01: Free-run stop
− 5-24
135Fh Cooling Fan Operation b092 R/W
00: Always
01: Only during operation
(including 5 minutes
after power on/stop)
02: Depends on the fin
temperature
−
5-127
1360h
Cooling Fan Total
Operation Time Clear
b093 R/W
00: Operation time count
01: Clear (Return to 00 after
clear)
−
1361h
Initialization Target
Selection
b094 R/W
00: All data
01: All data other than
terminals/
communication
02: U*** registration function
only
03: Other than U***
registration function
− 5-174
1362h
Regenerative Braking
Selection
b095 R/W
00: Disabled
01: Enable (Disable during
stop)
02: Enable (Enable during
stop)
−
5-141
1363h
Regenerative Braking
ON Level
b096 R/W 330 to 380/660 to 760 1 [V]
1364h
to
1366h
Reserved −−− − −
1367h Free V/f Frequency 1 b100 R/W 0 to Free V/f frequency 2 1 [Hz]
5-47
1368h Free V/f Voltage 1 b101 R/W 0 to 8000 0.1 [V]
1369h Free V/f Frequency 2 b102 R/W
Free V/f Frequency 1 to
Free V/f frequency 3
1 [Hz]
136Ah Free V/f Voltage 2 b103 R/W 0 to 8000 0.1 [V]
136Bh Free V/f Frequency 3 b104 R/W
Free V/f Frequency 2 to
Free V/f frequency 4
1 [Hz]
136Ch Free V/f Voltage 3 b105 R/W 0 to 8000 0.1 [V]
136Dh Free V/f Frequency 4 b106 R/W
Free V/f Frequency 3 to
Free V/f frequency 5
1 [Hz]
136Eh Free V/f Voltage 4 b107 R/W 0 to 8000 0.1 [V]
136Fh Free V/f Frequency 5 b108 R/W
Free V/f Frequency 4 to
Free V/f frequency 6
1 [Hz]
1370h Free V/f Voltage 5 b109 R/W 0 to 8000 0.1 [V]
1371h Free V/f Frequency 6 b110 R/W
Free V/f Frequency 5 to
Free V/f frequency 7
1 [Hz]
1372h Free V/f Voltage 6 b111 R/W 0 to 8000 0.1 [V]
1373h Free V/f Frequency 7 b112 R/W
Free V/f Frequency 6 to 400
(1000) (Hz)
1 [Hz]
1374h Free V/f Voltage 7 b113 R/W 0 to 8000 0.1 [V]
1375h
to
137Ah
Reserved −−− − −
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
