Omron 3G3MX2 - Page 353

6-50
6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
1341h
Window Comparator FV
Hysteresis Width
b062 R/W
0. to 10. (upper limit: (b061
− b062)/2)
1 [%]
5-132
1342h
Window Comparator FI
Upper Limit Level
b063 R/W
0. to 100. (lower limit: b064
+ b065 × 2)
1 [%]
1343h
Window Comparator FI
Lower Limit Level
b064 R/W
0. to 100. (upper limit: b063
− b065 × 2)
1 [%]
1344h
Window Comparator FI
Hysteresis Width
b065 R/W
0. to 10. (upper limit: (b063
− b064)/2)
1 [%]
1345h
to
1348h
Reserved −−− − −
1349h
Analog Operation Level
at FV Disconnection
b070 R/W 0 to 100/255 (no) 1 [%]
5-132
134Ah
Analog Operation Level
at FI Disconnection
b071 R/W 0 to 100/255 (no) 1 [%]
134Bh
to
134Dh
Reserved −−− − −
134Eh Ambient Temperature b075 R/W −10 to 50 1 [°C] 5-127
134Fh
to
1350h
Reserved −−− − −
1351h Integrated Power Clear b078 R/W
00: Disabled
01: Clear (Return to 00 after
clear)
−
5-7
1352h
Integrated Power Display
Scale
b079 R/W 1 to 1000 1
1353h
Reserved −−− − −
1354h
1355h Starting Frequency b082 R/W 10 to 999 (10000) 0.01 [Hz] 5-57
1356h Carrier Frequency b083 R/W 20 to 150 (100) 0.1 [kHz] 5-51
1357h Initialization Selection b084 R/W
00: Initialization disabled
01: Fault monitor clear
02: Initializes data
03: Fault monitor clear +
Data initialization
04: Do not set.
−
5-174
1358h
Initialization Data
Selection
b085 R/W 00: Do not change. −
1359h
Frequency Conversion
Coefficient
b086 R/W 1 to 9999 0.01 5-4
135Ah STOP Key Selection b087 R/W
00: Enabled
01: Disabled
02: Only resetting enabled
− 5-84
135Bh Free-run Stop Selection b088 R/W
00: 0 Hz restart
01: Frequency matching
restart
02: Frequency pull-in restart
− 5-103
135Ch
Automatic Carrier
Reduction
b089 R/W
00: Disabled
01: Enabled, depends on
current
02: Enabled, depends on
the fin temperature
− 5-52
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
