6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
1329h
User Parameter
Automatic Setting
Function
b039 R/W
00: Disabled
01: Enabled
− 5-177
132Ah Torque Limit Selection b040 R/W
00: Four-quadrant separate
setting
01: Terminal switching
02: Analog voltage input
03: Optional board
−
5-153
132Bh
Torque Limit 1 (four-
quadrant mode forward
power running)
b041 R/W 0 to 200/255 (no) 1 [%]
132Ch
Torque Limit 2 (four-
quadrant mode reverse
regeneration)
b042 R/W 0 to 200/255 (no) 1 [%]
132Dh
Torque Limit 3 (four-
quadrant mode reverse
power running)
b043 R/W 0 to 200/255 (no) 1 [%]
132Eh
Torque Limit 4 (four-
quadrant mode forward
regeneration)
b044 R/W 0 to 200/255 (no) 1 [%]
132Fh
Torque LADSTOP
Selection
b045 R/W
00: Disabled
01: Enabled
− 5-155
1330h
Reverse Rotation
Prevention Selection
b046 R/W
00: Disabled
01: Enabled
− 5-157
1331h
Reserved −−− − −
1332h
1333h
Heavy Load/Light Load
Selection
b049 R/W
00: Heavy load mode
01: Light load mode
− 5-13
1334h
Controlled Deceleration
on Power Loss
b050 R/W
00: Disabled
01: Deceleration stop
02: Constant voltage
(without recovery)
03: Constant voltage (with
recovery)
−
5-106
1335h
DC Bus Voltage Trigger
Level of Ctrl. Decel
b051 R/W 0 to 10000 0.1 [V]
1336h
Deceleration Hold Level
of Ctrl. Decel
b052 R/W 0 to 10000 0.1 [V]
1337h
Deceleration Time of
Ctrl. Decel
b053
(HIGH)
R/W
1 to 360000 0.01 [s]
1338h
b053
(LOW)
R/W
1339h
Freq. Drop to start Ctrl.
Decel
b054 R/W 0 to 1000 0.01 [Hz]
133Ah
to
133Eh
Reserved −−− − −
133Fh
Window Comparator FV
Upper Limit Level
b060 R/W
0. to 100. (lower limit: b061
+ b062 × 2)
1 [%]
5-132
1340h
Window Comparator FV
Lower Limit Level
b061 R/W
0. to 100.
(upper limit: b060 − b062 ×
2)
1 [%]
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
