6-62
6-8 List of Modbus Communication (Modbus-RTU) Data
SYSDRIVE MX2 Series USER'S MANUAL (3G3MX2-A@@@@)
6
Communication Function
1492h
Logic Output Signal 1
Selection 1
C142 R/W
Same with C021 and C022
(Except that "no," 62, 63,
and LOG1 to LOG3 cannot
be selected.)
−
5-125
1493h
Logic Output Signal 1
Selection 2
C143 R/W
Same with C021 and C022
(Except that "no," 62, 63,
and LOG1 to LOG3 cannot
be selected.)
−
1494h
Logic Output Signal 1
Operator Selection
C144 R/W
00: AND
01: OR
02: XOR
−
1495h
Logic Output Signal 2
Selection 1
C145 R/W
Same with C021 and C022
(Except that "no," 62, 63,
and LOG1 to LOG3 cannot
be selected.)
−
1496h
Logic Output Signal 2
Selection 2
C146 R/W
Same with C021 and C022
(Except that "no," 62, 63,
and LOG1 to LOG3 cannot
be selected.)
−
1497h
Logic Output Signal 2
Operator Selection
C147 R/W
00: AND
01: OR
02: XOR
−
1498h
Logic Output Signal 3
Selection 1
C148 R/W
Same with C021 and C022
(Except that "no," 62, 63,
and LOG1 to LOG3 cannot
be selected.)
−
1499h
Logic Output Signal 3
Selection 2
C149 R/W
Same with C021 and C022
(Except that "no," 62, 63,
and LOG1 to LOG3 cannot
be selected.)
−
149Ah
Logic Output Signal 3
Operator Selection
C150 R/W
00: AND
01: OR
02: XOR
−
149Bh
to
14A3h
Reserved −−− − −
14A4h
Input Terminal 1
Response Time
C160 R/W 0 to 200 1
5-32
14A5h
Input Terminal 2
Response Time
C161 R/W 0 to 200 1
14A6h
Input Terminal 3
Response Time
C162 R/W 0 to 200 1
14A7h
Input Terminal 4
Response Time
C163 R/W 0 to 200 1
14A8h
Input Terminal 5
Response Time
C164 R/W 0 to 200 1
14A9h
Input Terminal 6
Response Time
C165 R/W 0 to 200 1
14AAh
Input Terminal 7
Response Time
C166 R/W 0 to 200 1
14ABh
to
14ACh
Reserved −−− − −
Register
No.
Function name
Parameter
No.
R/W
Monitor and setting
parameters
Data
resolution
Page
