Omron 3G3RX Series User Manual

5 - 21
5 Drive Programming User Variables
Drive Programming User’s Manual (I580-E2)
5-7 Multi-function Output Variables
5
 MX2 only
 RX only
LOC Low current signal R C021 to C026  43
IRDY Operation ready R C021 to C026  50
FWR Forward run signal R C021 to C026  51
RVR Reverse run signal R C021 to C026  52
MJA Fatal fault signal R C021 to C026  53
WCO Window comparator FV R C021 to C026  54
WCOI Window comparator FI R C021 to C026  55
Function variable Description R/W Reference
FREF Frequency command source R C001 to C007  58
REF RUN command source R C001 to C007  59
SETM Motor 2 selection R C001 to C007  60
EDM Safety device monitor R C001 to C007  62
Function variable Description R/W Reference
IP Signal during momentary power interruption R C021 to C026  08
O2Dc Analog FE disconnection detection R C021 to C026  29
LOG 4 Logic operation output 4 R C021 to C026  36
LOG 5 Logic operation output 5 R C021 to C026  37
LOG 6 Logic operation output 6 R C021 to C026  38
WCO2 Window comparator FE R C021 to C026  56
Function variable Description R/W Reference
