5 Drive Programming User Variables
5 - 20
Drive Programming User’s Manual (I580-E2)
5-7 Multi-function Output Variables
You can execute the functions which can be allocated to the multi-function output terminals by using the
Drive Programming program. The following variables correspond to the functions which can be allo-
cated to the multi-function output terminals.
Setting each variable to 1 (ON) or 0 (OFF) causes the same operation as when the multi-function out-
put function turns the multi-function output terminal ON/OFF. You can monitor the status on the pro-
gram even if you do not set each function in the parameters Multi-function Output Selection (MX2:
C021 and C022/RX: C021 to C025 ) or Multi-function Relay Output (MA, MB) Function Selection
(C026). The Reference column in the following table shows the function setting data for the inverter. For
details on each function,
refer to the MX2 User's Manual (I570-E2) or the RX User's Manual (I560-E2) .
Precautions for Correct Use
When the Drive Programming program is stopped, the status of the multi-function output vari-
ables is not retained but updated according to the actual function status.
 MX2 and RX
Function variable Description R/W Reference
RUN Signal during RUN R C021 to C026  00
FA1 Constant speed arrival signal R C021 to C026  01
FA2 Set frequency exceeded signal R C021 to C026  02
OL Overload warning R C021 to C026  03
OD Excessive PID deviation R C021 to C026  04
AL Alarm signal R C021 to C026  05
FA3 Set-frequency only signal R C021 to C026  06
OTQ Overtorque/Undertorque signal R C021 to C026  07
UV Signal during undervoltage R C021 to C026  09
TRQ Torque limit R C021 to C026  10
RNT RUN time over R C021 to C026  11
ONT Power ON time over R C021 to C026  12
THM Electronic thermal warning R C021 to C026  13
BRK Brake release R C021 to C026  19
BER Brake error R C021 to C026  20
ZS 0 Hz detection signal R C021 to C026  21
DSE Excessive speed deviation R C021 to C026  22
POK Position ready R C021 to C026  23
FA4 Set frequency exceeded signal 2 R C021 to C026  24
FA5 Set-frequency only signal 2 R C021 to C026  25
OL2 Overload warning 2 R C021 to C026  26
ODc Analog FV disconnection detection R C021 to C026  27
OIDc Analog FI disconnection detection R C021 to C026  28
FBV PID feedback comparison signal R C021 to C026  31
NDc Communications disconnection detection R C021 to C026  32
LOG1 Logic operation output 1 R C021 to C026  33
LOG 2 Logic operation output 2 R C021 to C026  34
LOG 3 Logic operation output 3 R C021 to C026  35
WAC Capacitor life warning signal R C021 to C026  39
WAF Cooling fan life warning signal R C021 to C026  40
FR Starting contact signal R C021 to C026  41
OHF Cooling fin overheat warning R C021 to C026  42
