Omron 3G3RX Series User Manual

5 Drive Programming User Variables
5 - 18
Drive Programming User’s Manual (I580-E2)
 MX2 only
CS Commercial switching R/W C001 to C008  14
SFT Soft lock R/W C001 to C008  15
AT (Analog input switching) R/W C001 to C008  16
RS Reset R/W C001 to C008  18
STA 3-wire start R/W C001 to C008  20
STP 3-wire stop R/W C001 to C008  21
F-R (F/R)
*1
3-wire forward/reverse R/W C001 to C008  22
PID PID disabled R/W C001 to C008  23
PIDC PID integral reset R/W C001 to C008  24
UP Remote operation accelerated R/W C001 to C008  27
DWN Remote operation decelerated R/W C001 to C008  28
UDC Remote operation data clear R/W C001 to C008  29
OPE Forced operator function R/W C001 to C008  31
SF1 to SF7 Multi-step speed setting bit 1 to 7 R/W C001 to C008  32 to 38
OLR Overload limit switching R/W C001 to C008  39
TL Torque limit enabled R/W C001 to C008  40
TRQ1 and 2 Torque limit switching 1 and 2 R/W C001 to C008  41 and 42
BOK Brake confirmation R/W C001 to C008  44
LAC LAD cancel R/W C001 to C008  46
PCLR Current position clear R/W C001 to C008  47
ADD Set frequency A145 addition R/W C001 to C008  50
F-TM Forced terminal block R/W C001 to C008  51
ATR Torque reference input permission R/W C001 to C008  52
KHC Integrated power clear R/W C001 to C008  53
AHD Analog command held R/W C001 to C008  65
CP1 to 3 Position command selection 1 to 3 R/W C001 to C008  66 to 68
ORL Origin search limit signal R/W C001 to C008  69
ORG Origin search startup signal R/W C001 to C008  70
SPD Speed/Position switching R/W C001 to C008  73
*1. The shortened name of the function option for multi-function input is different from the function variable name.
The shortened name of the function option for multi-function input is shown in ( ).
Function variable Description R/W Reference
RS485 (485)
*1
*1. The shortened name of the function option for multi-function input is different from the function variable name.
The shortened name of the function option for multi-function input is shown in ( ).
Start co-inverter communication R/W C001 to C007  81
HLD Retain output frequency R/W C001 to C007  83
ROK Permission of RUN command R/W C001 to C007  84
DISP Display fixed R/W C001 to C007  86
Function variable Description R/W Reference
