9 LX inverter
9 - 6
Drive Programming User’s Manual (I580-E2)
9-4 Drive Programming User Variables
You can use the inverter's multi-function input terminals as the input terminal variables X(00) to X(11)
for the Drive Programming function by setting these multi-function input terminals to the general-pur-
pose input MI1 to MI12.
You can also use the input terminal variables X(00) to X(11) as word-access data, which are set to the
lower byte by using the variable Xw.
• The status of the multi-function input terminals S1 to S7 is captured and set as bit-size variables. This
variable is read-only.
• When the Multi-function Input S1 to S7 Selection (C001 to C007) are set to 49 to 60 (MI1 to MI11:
General-purpose input), the status of the input terminals S1 to S7 is captured and set as the input ter-
minal variables X(00) to X(11) of the Drive Programming.
Numbers are given to the input terminal variables X(00) to X(11) according to the numerical order of
the set general-purpose inputs MI1 to MI11, not the terminal numbers S1 to S7.
• The input terminal variable (word access) Xw is a function to use the input terminal variables X(00) to
X(11) as a word-size variable. This variable is read-only.
• The input terminal variables X(00) to X(11) are set to the lower byte. For the upper byte and unused
input terminal variables, zero is read out.
9-4-1 Input/Output Terminal Variables
Input Terminal Variables X(00) to X(11)
Function
variable
Description Data range
Default
data
Unit Data size R/W
X(00) to
X(11)
Input terminal variable
(bit access)
0: OFF
1: ON
0 bit R
Function variable
Setting for Multi-function Input Selection
(C001 to C007)
X(00) 49: MI1
X(01) 50: MI2
X(02) 51: MI3
X(03) 52: MI4
X(04) 53: MI5
X(05) 54: MI6
X(06) 55: MI7
X(07) 56: MI8
X(08) 57: MI9
X(09) 58: MI10
X(10) 59: MI11
X(11) 60: MI12
Function
variable
Description Data range
Default
data
Unit Data size R/W
Xw Input terminal variable
(word access)
0 to 255 0 Unsigned
1 word
R
Bit 12 to 15 11 10 9 8 7 6 5 4 3 2 1 0
Function Not used X(11) X(10) X(09) X(08) X(07) X(06) X(05) X(04) X(03) X(02) X(01) X(00)
