8 - 3
8 Errors and Remedies
Drive Programming User’s Manual (I580-E2)
8-1 Troubleshooting
8
8-1-2 Drive Programming Operation on Error Reset
The Drive Programming operation on error reset varies with the reset input method and the setting for
the Reset Selection (C102). The following table shows the operation for each case.
 Reset input method
• To restart the Drive Programming, set the Multi-function Input Selection (MX2: C001 to C007/RX:
C001 to C008) to 18 (RS (Reset)) and turn ON the corresponding input terminal.
• You cannot restart the Drive Programming by pressing the STOP/RESET key of the Digital Oper-
ator or the LCD Digital Operator (optional).
 Reset Selection (C102)
• To restart the Drive Programming by reset input, it is necessary to set the Reset Selection (C102)
to the value other than 03 (Trip reset only). You cannot restart the Drive Programming when 03
(Trip reset only) is set.
• When the Reset Selection (C102) is set to 00 (Trip reset at power-on) or 01 (Trip reset at
power-off), the Drive Programming can be restarted by a reset input even when there is no trip.
• When the Reset Selection (C102) is set to 02 (Enabled only during trip), the Drive Programming
can be restarted only when there is a trip detected by the inverter.
It does not restart with a reset input when there is no trip in the inverter.
*1. The table assumes that the PRG terminal is ON in the case that the Drive Programming Function Selection
(A017) is set to 01. If the PRG terminal is OFF, the Keep stop operation applies to all cases, because the pro-
gram does not run.
*2. To restart the program, set the Drive Programming Function Selection to 00 (Disabled) first, and then change
it to 02 (Enabled (Start/stop at power on/off)). Also, you can restart it by turning ON the PRG terminal again, if
A017  01.
*3. If C102  03, only the trip is cleared by the reset operation. The internal calculation data such as current val-
ues are not initialized.
8-1-2 Drive Programming Operation on Error Reset
Operation
Program
status
Trip
status
Reset with control terminal
Reset with Operator's
STOP/RESET key
C102 00
or 01
C102 02 C102 03
C102 00
or 01
C102 02 C102 03
Drive Program-
ming operation
*1
During run Normal
status
Restart Keep run Keep run Keep run Keep run Keep run
During
trip
Restart Restart Keep run Keep run Keep run Keep run
During
stop
Normal
status
Restart Keep
stop
*2
Keep
stop
*2
Keep
stop
*2
Keep
stop
*2
Keep
stop
*2
During
trip
Restart Restart Keep
stop
*2
Keep
stop
*2
Keep
stop
*2
Keep
stop
*2
Inverter's reset operation Normal
status
Reset Disabled Disabled Reset Disabled Disabled
During
trip
Reset Reset
Reset
*3
Reset Reset
Reset
*3
