9 LX inverter
9 - 4
Drive Programming User’s Manual (I580-E2)
Commands Inverter control • Executes and stops forward/reverse operation
• Generates a trip by the Drive Programming (E50 to E59/10 points)
• Frequency reference and acceleration/deceleration time settings
Function variable User parameter vari-
able
U(00) to U(31)/32 points
Internal user variable UL(00) to UL(07)/8 points
Frequency reference
variable
SET-Freq
Acceleration time vari-
able
ACCEL
Deceleration time vari-
able
DECEL
Inverter monitor vari-
able
FM, Iout, Dir, PID-FB, F-CNV, Tmon, Vout, Power, RUN-Time, ON-Time,
POS, STATUS, DCV, ERR-CNT, ERR(1) to ERR(6), and UMon(0) to
UMon(2)
Multi-function input
variable
The function options of the Multi-function Input S1 Selection (C001) for the
inverter are available.
UP, DWN, SPD1, SPD2, SPD3, SET, FRS, EXT, SFT, RS, OLR, TL, TRQ1,
TRQ2, PCLR, EMP, INSP, RL, COK, BOK, FP1 to FP6, PAL, TCL, LVS, NFS,
PRG, CMC, GS1, and GS2
Multi-function output
variable
The function options of the Multi-function Output P1 Selection (C021) for the
inverter are available.
RUN, FA1, FA2, OL, AL, FA3, OTQ, IP, UV, TRQ, RNT, ONT, THM, ZS, POK,
FA4, FA5, OL2, TH-C, NDc, WAC, WAF, FR, OHF, LOC, IRDY, FWR, RWR,
MJA, CON, BRK, UPS, UPD, GMON, MPS, and SEQ
Input terminal variable X(00) to X(06)/7 points
Extended I/O option
input variable
X(07) to X(11)/5 points (with 3G3AX-EIO-E expansion card)
Output terminal vari-
able
Y(00) to Y(03)/4 points
Extended I/O option
output variable
Y(04) to Y(06)/3 points (with 3G3AX-EIO-E expansion card)
Internal user contact UB(0) to UB(7)/8 points
Timer output contact TD(0) to TD(7)/8 points
Timer counter variable TC(0) to TC(7)/8 points
Item Specifications
